CUTMaster Super Plus is a specialised spreading and cutting table, built for faster unwinding and cutting of thick and layered materials.
Featuring a low-speed cutter, it works best with quilted materials, insulation, filters, foams, and similar.
Main Features
- spreads rolls up to 320 cm wide
- load capacity up to 150 kg
- automatic cutter (1 m/s cutting speed)
- any length in segments of 1.40 m
- dust-proof spreader rails
- numerous optional accessories
CUTMaster Super Plus uses a low-speed cutter for thick fabrics.
For thin materials only, see the Super model.
Cutter
CUTMaster Super Plus uses an automatic cutter running at 1 m/s cutting speed. The low-speed cutting head cuts materials up to 25 mm thick.
The control unit includes a cut counter with manual adjustment and reset, and lets the operator set the cutting width and track rail lift height on the panel.
Blade covers and an emergency switch protect the operator during operation.
Spreading Machine
The CUTMaster spreader runs on precision tracks that keep it moving smoothly and without jams — even in dusty cutting room conditions.
The light yet stable construction keeps the spreader easy to move, and a single operator can handle the entire spreading process.
Two versions are available: standard with 80 kg load capacity and reinforced for heavy rolls up to 150 kg.
Base Configuration
CUTMaster Super Plus comes with a 3.2 m long table and a spreader with a capacity of up to 80 kg.
The fabric aligned with the front table edge is pressed firmly by the manual holding bar during spreading.
A cable power feed system runs along the spreader track, keeping the workspace clear.
CUTMaster comes in four models, from manual cutting to air-assisted system.
There is a setup for every workshop, material type, and production volume.
Not sure which model is right for you?
Contact us to schedule a free online meeting and we we’ll walk you through the options.
Or use our Product Advisor to narrow down the selection.
The modular design lets you select features that actually suit your work.
Use CUTMaster Super Plus configurator to customise it.
Simple Setup & Easy Operation
Assemble the CUTMaster yourself and get started the same day — the assembly manual and video tutorial walk you through every step of the installation process. No technical skills required.
Ease of operation was the top principle behind CUTMaster’s design. All repeatable actions are simplified to the minimum to save time and effort. An average roll can be spread over the table within 15 minutes.
Watch the video and see how easy it is.
Maintenance & Support
CUTMaster Super requires no regular servicing — just cleaning and replacing blades, sharpeners, and carbon brushes. Video tutorials are available for all maintenance tasks, and all consumables can be ordered in a spare parts kit.
Each CUTMaster includes a complete support package. We offer full post-warranty service and spare parts shipped by courier within 24 hours.
We provide full support in four key areas:
assembly of the table
step-by-step videos for simple assembly
service and spare parts
fast response and spare parts shipped within 24 hours
video tutorials
24/7 access to troubleshooting guides
online help
chat with our specialists when necessary
Smart investment that saves time and money
CUTMaster increases productivity by 50% to over 100%, with the purchase cost amortised within a few months.
Applications
CUTMaster is used across garment manufacturing, home textiles, automotive upholstery, furniture production, and technical fabrics – wherever fast, multi-layer fabric spreading and cutting are needed.
From sportswear and bedding to car seat covers, aerospace interiors, and industrial nonwovens – it accelerates material handling and lay preparation.
Frequently Asked Questions
What materials can RollMaster cut? Will it cut mine?
RollMaster can cut a wide range of materials including most woods, plastics, foams, fabrics, and soft metals like aluminum. If you’re unsure whether it can handle your specific material, feel free to contact us with details—chances are, it can!
How much does maintenance and service cost?
Maintenance and service costs can vary depending on usage and specific needs. We offer flexible support options to suit different requirements—please contact us for more details.
How long is the warranty?
We provide a standard 1-year warranty for all B2B customers.
Technical Specification
Cutting Table
| Width | 182–322 cm |
| Length | any length in segments of 1.4 m |
| Height | 86–89 cm, regulated |
| Frame | powder coated steel profiles |
| Table top | 25 mm, 2 mm PVC framed |
| Bottom shelves | 18 mm, optional |
Spreading Machine
| Operation | manual |
| Spreading height | up to 20 cm |
| Roll weight | up to 80 kg, optionally up to 150 kg |
| Roll dimension | up to 50 cm, optionally up to 80 cm |
| Spreader track | galvanised steel profiles |
Cutting Device
| Operation | automatic |
| End cutter track lift | motorised |
| Setting cutting width | yes |
| Layer counter | yes, with editing function |
| Protection equipment | emergency button, blade covers |
| Cutting height | 25 mm |
| Blade speed | 800 rpm |
| Power | 300 W |
| Voltage | 230 V |
Other
| Holding bar | manual, optionally pneumatic |
Each CUTMaster can be
adapted to your needs
Choose dimensions and features that match your production goals.
Configure your own setup with our online tool.
RollMaster Super cuts rolled materials precisely to the exact formats. Perfect for window blinds, curtains, upholstery and bedding producers who need fast, accurate cuts every time.
Built with a lightweight yet incredibly strong construction that lasts decades, not years.
The thick 25 mm, edge-sealed tabletop resists warping and damage from daily industrial use.
Main Features
- cuts automatically at 1 m/s
- 1 mm cutting precision
- handles rolls up to 320 cm wide
- expandable with LED backlight, speed adjustment and more
RollMaster Super cutting height is 5 mm.
For thicker materials, check out Super Plus model.
Thanks to the modular design, you can create a table tailored to your needs. Start with basic setup, add extensions later as your business grows.
Technical Specification
Cutting Table
| Cutting width | up to 320 cm |
| Length | 200 – 500 cm or other on request |
| Height | 86-89 cm, regulated |
| Frame | powder coated steel profiles |
| Table top | 25 mm, 2 mm PVC framed |
Cutting Device
| Cutting width | up to 320 cm |
| Length | 200 – 500 cm or other on request |
| Height | 86-89 cm, regulated |
| Frame | powder coated steel profiles |
| Table top | 25 mm, 2 mm PVC framed |
Control Features
| Cutting width | up to 320 cm |
| Length | 200 – 500 cm or other on request |
| Height | 86-89 cm, regulated |
| Frame | powder coated steel profiles |
| Table top | 25 mm, 2 mm PVC framed |
Other
| Cutting width | up to 320 cm |
| Length | 200 – 500 cm or other on request |
| Height | 86-89 cm, regulated |
| Frame | powder coated steel profiles |
| Table top | 25 mm, 2 mm PVC framed |
Simple Setup Process
Assemble RollMaster yourself and get started the same day. With our video tutorial, the installation process is as simple as joining lego bricks.
Moreover, the operator learns how to work with it in 30 minutes. No special training needed – just measure, set, and cut. Simple as that.
Watch the video and see how easy it is.
Send samples of your materials for testing
RollMaster Super cuts almost any kind of thin materials including cotton, linen, denim, silk, woven fabric, leather, polyester, films, technical textiles, synthetic fibres, filter materials and much more.
Not sure if your materials will cut perfectly?
Send us samples and receive a free video report with our expert analysis.
Maintenance & Support
Built to last decades, backed by support when you need it. Focus on production, we handle the rest.
assembly of the table
Step-by-step videos make assembly simple
service and spare parts
Fast response and spare parts shipped within 24 hours
video tutorials
24/7 access to troubleshooting guides
expanding the system
Frequently Asked Questions
What materials can RollMaster cut? Will it cut mine?
RollMaster can cut a wide range of materials including most woods, plastics, foams, fabrics, and soft metals like aluminum. If you’re unsure whether it can handle your specific material, feel free to contact us with details—chances are, it can!
How much does maintenance and service cost?
Maintenance and service costs can vary depending on usage and specific needs. We offer flexible support options to suit different requirements—please contact us for more details.
How long is the warranty?
We provide a standard 1-year warranty for all B2B customers.
Every RollMaster can be tailored to your needs
Choose size and features that match your production goals. Find your ideal setup in minutes.
